adss

ADSS double jacket long span self-supporting non- metal optic fiber cable

Product Information:ADSS cable is a loose tube-stranded structure. The optical fiber is 250pm, and the loose tube is made of high-modulus plastic, which is filled with a waterproof compound. ln the ce

  • Introduction to optical cables
 Product Information:

ADSS cable is a loose tube-stranded structure. The optical fiber is 250pm, and the loose tube is made of high-modulus plastic, which is filled with a waterproof compound. ln the center of the cable core is an FRP-strength member, The loose tube (and the filling rope) is twisted around the central reinforcement core to form a compact and round cable core, and the gap in the cable core is filled with a water-blocking filler. The outer of the cable is a polyethylene (PE) inner sheath, then twisted high tensile strength aramid, and the outermost is the electric tracking (AT) outer sheath.


 Product Characteristics:
  • All-electrical self-supporting aerial fiber optic cable, with no metal material in the structure, can be set up without interruption.

  • Large number of fiber cores, lightweight, can be laid with the power line, saving resources.

  • Adopt high tensile strength aramid material to withstand strong tension and prevent cockles and gunshots.

  • Small thermal expansion, the variation of the arc of the cable line is small when the temperature changes greatly.

  • Double jacket, PE/AT Oute sheath.

  • Large span, the maximum span exceeds 1000 meters.

  • Life expectancy greater than 30 years.



 Environmental Characteristics:
  • Transport/storage temperature: -40°C to +70C


 Application:
  • Self-supporting aerial
