Technical Specifications of LC Patch Panel: Ensuring Device Compatibility and Technical Requirements

Technical Specifications of LC Patch Panel: Ensuring Device Compatibility and Technical Requirements

When selecting and purchasing an "LC Patch Panel", understanding its technical specifications is crucial to ensure device compatibility and meet technical needs. Below is a detailed explanation of the technical specifications of the LC Patch Panel, designed to provide a clearer understanding of the various parameters and capabilities of the product.

I. Basic Parameters

1. Brand and Model: Brands and models may vary depending on suppliers and product lines. Choosing a reputable brand and a suitable model for your needs can ensure product quality and reliability.

2. Dimensions: Commonly available in a 19-inch width, with varying heights (U numbers) and depths depending on the specific product. For instance, there are options such as 2U, 1U, and other heights to choose from.

3. Color: Typically available in black or other dark colors to blend in with various server rooms and cabinets.

II. Fiber Parameters

1. Fiber Type: Supports single-mode or multi-mode fibers, allowing you to choose the appropriate fiber type based on your specific application scenario.

2. Number of Fibers: Ranges from 12 to 96 cores, depending on the product model and application requirements.

   www.adsscable.cn

3. Fiber Connector Type: Utilizes LC connectors to ensure compatibility with other LC interface devices.

III. Technical Specifications

1. Material: The main body is usually made of metal, such as cold-rolled steel, to ensure stability and durability.

2. Fiber Management: Features built-in fiber management modules like fiber clamps and adapters for neat fiber arrangement and connection.www.adsscable.cn

3. Port Type: Supports LC port connections to meet the access needs of various fiber devices.

4. Fiber Capacity: Depending on the product model, the fiber capacity can reach 12/24/48/96 cores, catering to networks of different sizes.

IV. Certifications and Standardswww.adsscable.cn

1. Certifications: Products should be CE, ISO, RoHS, and other relevant certifications to ensure compliance with international standards and environmental requirements.

2. Standards: Conforms to industry standards such as ANSI/TIA/EIA-568-B.2, EN 50173, ensuring universality and interchangeability.

V. Additional Features

1. Modular Design: Supports modular installation and configuration for easy expansion and upgrades based on actual needs.

2. Easy Installation and Maintenance: Features a user-friendly design for straightforward installation, disassembly, and maintenance, reducing operational costs.

3. Customization Services: Some suppliers offer customization services, allowing for tailored LC Patch Panels with specific specifications and functions according to customer requirements.

In conclusion, understanding the technical specifications of the LC Patch Panel is essential for selecting equipment that meets your needs. By focusing on basic parameters, fiber parameters, technical specifications, certifications, standards, and additional features, you can ensure that the chosen device offers excellent compatibility and technical performance, satisfying your network construction and application demands.
